Pistol Cable Nutrunner Tensor SR ETP SR31-25-10 8434108106

The robust, yet compact, Pistol Cable Nutrunner Tensor SR with built-in torque transducer delivers an unmatched power-to-weight ratio and Industry leading accuracy. The shorter body of Tensor SR is ideal for cramped spaces and allows for better operator ergonomics without sacrificing speed, power or accuracy. In addition, the Tensor SR provides safety-critical accuracy and fully traceable results.


The robust, yet compact, Pistol Cable Nutrunner Tensor SR with built-in torque transducer delivers an unmatched power-to-weight ratio and Industry leading accuracy. The shorter body of Tensor SR is ideal for cramped spaces and allows for better operator ergonomics without sacrificing speed, power or accuracy. In addition, the Tensor SR provides safety-critical accuracy and fully traceable results.

Features:

+/-5% over six sigma accuracy

Built-in Transducer and TurboTorque

High free-run speed

Direct and robust gear box

Easy function button configuration

Built-in signal and front lights

ESD certified


Benefits:

Full traceability

One-handed operation

Compact and fast

Intuitive operator feedback


Technical Specifications
Imperial Metric                            Dimension & weight
Dimension & weight
Height179 mm
Length                                      210 mm
Overall width3/8"
Weight                                      1.8 lb
Certifications, standards & directives
CCC certifiedNo
CQC certifiedNo
EAC certifiedYes
EU Legislation2006/42/EC (MD)||2011/65/EU
(RoHS)||2014/30/EU (EMC)||2015/863/EU
(RoHS amendment)
EU StandardEN 61000-6-2:2019||EN 61000-6-4:2019||EN
62841-1:2015+AC:2015||EN 62841-2-
2:2014+AC:2015||EN ISO 12100:2010
KC certifiedYes
KC IDR-REI-50A-ETPSR31-20-10
UK RegulationsS.I. 2008/1597||S.I. 2012/3032||S.I. 2016/1091
UK StandardBS EN 62841-1:2015||BS EN 62841-2-
2:2014||BS EN IEC 61000-6-2:2019||BS EN IEC
61000-6-4:2019||BS EN ISO 12100:2010
WEEE5 - Small equipment <50cm
Torque
Torque range max                                                        18.4 ft-lb
Torque range min                             3.7 ft-lb
Torque scatter 3s≤ 5 %
Design & Functions
Model type                                                                     Pistol
Output type                                                         Square, Male
SCIP644e5221-93ba-411d-bf78-1dc70cec5233
Shut-off systemTransducer
Tool familySR
Power
Motor power                                                                  1400 W
Motor voltage type                             3 a.c.
Motor voltage                                 200 V
Noise & vibrations
Additional sound value85 dB(A)
Additional vibration value25 m/s²
Sound pressure                            < 70 dB(A)
Sound standard                             ISO15744
Vibration standardISO28927-1
Vibration value<2.5 m/s²
Speed
Speed range max 2010 r/min
