5 Series Non-Reversible Air Drill, Pistol Grip
With variable speed control, a great power-to-weight ratio and high quality materials, the 5 Series Pistol Non-Reversible drills deliver day after day. They’re tools you can count on.
- Product Details
- Technical Specification
With variable speed control, a great power-to-weight ratio and high quality materials, the 5 Series Pistol Non-Reversible drills deliver day after day. They're tools you can count on.
Features
1.Performance
The ergonomic design of these pistol tools allow you to work precisely and efficiently, so your jobs will always be done with ease.
2.User Comfort
The power-to-weight ratio of these tools were specifically designed to allow for faster completion of projects without user fatigue.
3.Durability
Built with high quality chuck, these tools are able to withstand harsh conditions.
| Model | Actuation | Reversible | Max. Working Torque (Nm) | Max. Working Torque (in-lb) | Free Speed (rpm) | Weight with Chuck (kg) | Weight with Chuck (lb) | Length with Chuck (mm) | Length with Chuck (in) | Bit Holder Capacity (in) | Bit Holder Capacity (mm) | Side to Center (mm) | Side to Center (in) | Sound Level dB(A) | Rated Power (hp) | Air Inlet | cfm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5AJST4 | Trigger Start | No | 2.3 | 20 | 4500 | 0.09 | 2 | 173 | 6.8 | 1/4 | 6 | 21 | 0.8 | 75 | 0.4 | 1/4 in. NPT | 17 |
| 5AKST4 | Trigger Start | No | 3.4 | 30.1 | 3000 | 0.09 | 2 | 173 | 6.8 | 1/4 | 6 | 21 | 0.8 | 75 | 0.4 | 1/4 in. NPT | 17 |
| 5ALST4 | Trigger Start | No | 4.5 | 39.8 | 2200 | 0.09 | 2 | 173 | 6.8 | 1/4 | 6 | 21 | 0.8 | 75 | 0.4 | 1/4 in. NPT | 17 |
| 5ANST6 | Trigger Start | No | 9 | 79.7 | 1000 | 1.3 | 2.8 | 207 | 8.1 | 3/8 | 10 | 21 | 0.8 | 75 | 0.4 | 1/4 in. NPT | 17 |
